Copper Wire Screen Medium Voltage Cable
| Cross-sectional Area (mm²) | Average overall diameter (mm) | Core | Reference weight (kg/km) | Conductor Resistance 20ºC Max (Ω/km) | |
| 50 | - | 26 | 1 | 1003 | ≤0.387 |
| 70 | - | 27 | 1 | 1233 | ≤0.268 |
| 95 | - | 29 | 1 | 1520 | ≤0.193 |
| 120 | - | 30 | 1 | 1799 | ≤0.153 |
| 150 | - | 32 | 1 | 2088 | ≤0.124 |
| 185 | - | 34 | 1 | 2482 | ≤0.0991 |
| 240 | - | 36 | 1 | 3080 | ≤0.0754 |
| 300 | - | 38 | 1 | 3674 | ≤0.0601 |
| 400 | - | 41 | 1 | 4572 | ≤0.0470 |
| 500 | - | 44 | 1 | 5890 | ≤0.0366 |
| 50 | - | 52 | 3 | 3318 | ≤0.727 |
| 70 | - | 55 | 3 | 4104 | ≤0.524 |
| 95 | - | 59 | 3 | 5049 | ≤0.387 |
| 120 | - | 62 | 3 | 5937 | ≤0.268 |
| 150 | - | 66 | 3 | 6896 | ≤0.193 |
| 185 | - | 69 | 3 | 8141 | ≤0.153 |
| 240 | - | 75 | 3 | 10075 | ≤0.124 |
| 300 | - | 80 | 3 | 12004 | ≤0.0991 |
| 400 | - | 86 | 3 | 14887 | ≤0.0754 |
Description Of Copper Wire Screen Medium Voltage Cable
Rated Temperature: 90℃
Rated Voltage: up to 26/35kV
Reference Standard: IEC60502-2
Conductor: Shaped and circular stranded copper conductors
Insulated: Insulated with XLPE
Sheathed:PVC
Screen: Copper Wire
Copper Wire Screen Medium Voltage Cable employ a woven or spiraled layer of fine copper wires, combining flexibility with reliable electromagnetic screen. This configuration is well-suited for applications requiring moderate movement, such as machinery connections or temporary power systems, where the cable must endure repeated bending without compromising performance. The design allows better heat dissipation and adaptability to irregular surfaces but may offer slightly lower shielding effectiveness compared to solid tape.
+
+
+
